ISDT 1-8S Safe Parallel XT60 Charging Board
ISDT PC-4860 1-8S Safe Parallel Board XT60 CNC Parallel Charging Board
Description:
Brand: ISDT
Model: PC-4860
Name: Safe Parallel Board
Size: 88*58*20 mm
Cable Length: 150 mm
Weight: 205 g
Specification:
Max Input Current: 40A
Max Output Current: 30A/Port
Max Balance Current : 2A
Balance Cells: 1s~8s
Plug: XT60
Balance Cable: 6S
Safety Beauty Efficiency are integrated
Faultless Security Assurance
32pcs Fuse,Support 40A input,4 Channels output,Aluminum case to avoid exploding or catching fire
Compact Size
ISDT Safe Parallel Board is developed with reasonable size and scientific segmentation design
to ensure high safety, efficient heat dissipation and comfortable hand feeling.
Precision CNC
Wire electrode cutting >> CNC >> Polising >> Sand blasting >> Anodizing >> assembling >> All inspection and packing
Customer reviews in rcgroups: Click for reference
Packing included:
1 x ISDT PC-4860 Safe Parallel Board
1 x XT60 Power Cable
1 x 6s Balance Cable
Type: | |
---|---|
Vendor: | |
Weight: |
0.0 lb |
I used two of these. one on each port on my Icharger. I can charge four 12S packs at once!
excellent board, Very compact and durable !!
The build quality is top notch, the included cable is 6S , but it can hamdle up to 8S?
Excellent parallel board, comes with balance lead connection & XT-60 pigtail. Feels very stout and looks great in my charger case.
Materials and construction are top quality, but the pins inside one balance port are misaligned making battery connection a chore. I was able to bend pins 1mm up for smoother connection. I like the security provided by fuses.
Great solid quad unit. Solid CNC aluminum sting and Excellent design 🤙🏼
This thing is heavy and solid with outstanding build quality. It may be a bit over engineered and expensive for what it does but I can tell this will be a parallel board you will be using for many many years, and the 32 per-cell fuses give you that extra piece of mind. What is your safety worth?
Very high quality. Makes charging multiple packs a breeze
Quality control seems to be in good shape as the box had absolutely no dents creases or anything of that sort. I ordered it the other day got it the next. And the price was on par. if you're thinking about ordering, just go do it. By the time you get done reading this you could have already had your product/s.
Takes the worry out of parallel charging. Super high quality feel and safety oriented
